700 GALLON BASE TRUCK MODELS:

FUEL CAPACITY:

OTHER FEATURES:

Beacon light
Auxiliary outlet with cutoff piped to curbside for optional wash down system
12 volt battery
Hydraulic temp gauge
Heavy duty hose guide
Heavy duty pressure regulator
Engine shroud
One each 20° and 30° cleaning nozzle, one heavy duty 15” tubular nozzle extension and one heavy duty (Tiger Tail)
Warranty is standard one year parts and labor, with exception of tank (5) and engine (2)

TRAILER FEATURES:

CONTROL PANEL AND CABINET:

Yanmar engines have a digital electronic control panel that presents an hour meter, oil pressure, voltage and throttle control
John Deere engines have an analog panel with Murphy safety shutdown switch and optional electronic throttle control
All control cabinets come standard with a beacon switch, ignition switch, water pressure gauge, reel speed control, reel in/out, emergency stop and electric clutch (water on/off)

TANK FEATURES

Water capacity is 700 gallon (2650 liters), consisting of two 350 gallon tanks.
Tank material is a black poly LLDPE (linear low density polyethylene).
UV inhibitor which prevents the development of plant growth (i.e. algae, mold, etc.).
The tank features an overhead air-gap fill and a curbside 2-½” brass fire hydrant fitting for easy and safe refill.
Cold weather recirculation system allows water to be re-circulated through main hose and back to tank for below freezing operation

HOSE REEL:

Standard reel capacity is 600’ of optional ¾” or 800’ of ½” high pressure hose and has air pressure clean-out connection
Dual reel capacities are 600’ of ½” and 600’ of ¾” of high pressure hose (for 40 gpm @ 3000 psi only)

Bin Stacking
